The device can be used to connect the thermoplastic tube of disposable liquid storage bag system and disposable mixing bag. No matter in the clean area or the unclean area, the exhaust aseptic nozzle can realize the aseptic connection of the air pipeline or the liquid filled pipeline, so as to facilitate the replenishment of liquid materials in different environments.

Equipment compatible with common specifications TPE pipeline (1/4"-3/4") to achieve aseptic welding in non-sterile environment, with liquid welding of various specifications of pipe support optional, can simply and quickly meet the process requirements of smooth welding surface, no impact on liquid flow rate.

It can be used to connect the thermoplastic tube of disposable liquid storage bag system and disposable mixing bag. No matter in the clean area and non-clean area, Yifeng industrial aseptic nozzle will be two hoses respectively embedded in the pipe clamp, the hose is cut by the blade and fused together, in the whole operation process, the blade always remains sterile and to heat source, so that in a non-sterile environment can easily achieve aseptic connection. Pipe clamp: Made of aviation aluminum alloy (not easy to wear), and accurate size. Blade: stainless steel material.

The heat sealing time is 1-1.5 min, according to the pipe size different applicable pipe specifications model TPE material welded pipe (Saint-Gobain C-Flex 374 and 082 series)

Od 6.4mm-19.1mm (1/4"-3/4")

Wall thickness 1.6mm-3.2mm (1/16"-1/8")

Overall dimensions 390*280*300 mm (L*W*H)
